VWIC3-2MFT-G703
VWIC3-2MFT-G703
0
VWIC3-2MFT-G703 Cisco Voice/WAN Card VWIC3-2MFT-G703 VWIC3-2MFT-G703 Overview Cisco third generation Voice / WAN T1/E1 interface card supports both voice and data application on Cisco ISR 2 1900/2900/3900 series platform. This module integrate with 2 T1/E1 interfaces which one port can configure for unstructured E1 (G.703) and the other port configure structured framed E1 (G.704) to support voice or WAN connectivity. VWIC3-2MFT-G703 Specification VWIC3-2MFT-G703 Manufacturer Cisco Part Number VWIC3-2MFT-G703 Device Type Interface module Form factor 2-Port G.703 Multiflex Trunk Voice/WAN Interface Card Specifications Number of Ports 2 T1 Support Yes E1 Support Yes Unstructured E1 (G.703) Support Yes Data Support WIC
VWIC3-2MFT-G703
Cisco Voice/WAN Card VWIC3-2MFT-G703
VWIC3-2MFT-G703 Overview
Cisco third generation Voice / WAN T1/E1 interface card supports both voice and data application on Cisco ISR 2 1900/2900/3900 series platform. This module integrate with 2 T1/E1 interfaces which one port can configure for unstructured E1 (G.703) and the other port configure structured framed E1 (G.704) to support voice or WAN connectivity.
VWIC3-2MFT-G703 Specification
|
VWIC3-2MFT-G703 |
|
|
Manufacturer |
Cisco |
|
Part Number |
VWIC3-2MFT-G703 |
|
Device Type |
Interface module |
|
Form factor |
2-Port G.703 Multiflex Trunk Voice/WAN Interface Card |
|
Specifications |
|
|
Number of Ports |
2 |
|
T1 Support |
Yes |
|
E1 Support |
Yes |
|
Unstructured E1 (G.703) Support |
Yes |
|
Data Support WIC Mode |
Yes |
|
Voice Support VIC* |
Yes |
|
Drop-and-Insert Multiplexing |
Yes |
|
Configuration Comparison |
|
|
Serial Data (channel-group*) |
2 total |
|
Voice CAS (ds0-group**) |
48 total (T1) |
|
PRI (pri-group***) |
2 total |
|
Drop & Insert (tdm-group****) |
48 total (T1) |
|
Network Management Features |
|
|
Telnet or Console |
Remote and local configuration, monitoring, and troubleshooting from Cisco IOS Software CLI |
|
Simple Network Management Protocol (SNMP) |
• Router and DSU/CSU managed by single SNMP agent; router, DSU, and CSU appear as a single network entity to user • Standard MIB (MIB II) • Cisco Integrated DSU/CSU MIB • RFC 1406 T1 MIB, Including Alarm Detection and Reporting |
|
SNMP Traps |
Generated in response to alarms |
